AX3 3" Round Adjustable

3" Precision Recessed New Construction & Remodel
    WarmDimTunable WhiteEnergy Star®CA Title 24/JA8Buy America(n) Option AvailableBuy America(n) Option AvailableLow UGR
  • Overview
  • Specifications
Read More
Read Less
Aperture Size 3 IN
Shape Round
Light Source LED - Dynamic, LED - Static
Lumens 600 LM, 800 LM, 1200 LM, 1500 LM, 2000 LM, 2500 LM, 3000 LM
CCT / LED Color 2700 K, 3000 K, 3500 K, 4000 K, Variable
CRI 80, 90, 95
Product Type Housing
Compliance Listing BAA and BABA, CA Title 24, Chicago Plenum, ENERGY STAR®, JA8, Low UGR
Environmental Listing ASTM Airtight, Damp Location, IC, IP65, Non-IC, Wet Location
Regulatory Listing cUL, UL
Control Platform nLight Wired
Dimming Protocol 0-10V, DALI, DMX, Forward Phase, Reverse Phase
Fixture Wattage 11, 12, 12.3, 12.5, 12.6, 12.7, 13.6, 13.8, 14, 14.2, 14.6, 19.7, 20.2, 25.8, 26.3, 32.9, 33.3, 7, 7.6
Voltage Rating 57VDC, 120, 120-277, 277, DC2DC 57VDC
Trim Style Angle-Cut, Bevel, Lensed, Pinhole, Reflector
Color Black, Clear, Wheat, White
Mounting Type Recessed
Series AX3

Read More Read Less

  • Suggested Replacement Products

PRODUCT INFORMATION

  • Spec Sheets

    Document Type Document Title Description Updated View
    Spec Sheet Aculux-AX3-Adjustable-3in-Round-Recessed-DC2DC.pdf AX3 Round 3" Adjustable DC2DC ARCHITECTURE 2/5/2025 View
    Spec Sheet Aculux-AX3-Recessed-3in-Round-Adjustable.pdf AX3 Round Adjustable New Construction Gen 4 1/14/2025 View
    Spec Sheet Aculux-AX3-Remodel-3in-Round-Recessed-ADJ_DL_WW.pdf AX3 Round Universal Remodel Gen 4 9/8/2023 View
    Design Select

    Need to Create a Submittal Spec Sheet?

    Take Me There

  • Photometry & Revit (BIM)

    Use %(percent) to separate search terms.
    Clear Filters

    {{pager.startIndex + 1}} - {{pager.endIndex + 1}} of {{pager.totalItems | number:0}} results

    Description Report Design Tools
    {{photometryItem.Catalog}} Report
    CLICK HERE to start your request for a BIM Model or IES file.

  • Technical Documents (e.g. Instruction Sheets, MSDS, CAD)

    Document Type Document Title Description Updated View
    Installation Instructions 912-00376-003 Rev.C DC2DC.pdf DC2DC 57VDC Supplemental Installation Sheet 3/11/2025 View
    Installation Instructions P2886.pdf AX3 and AX3SQ Flangeless Adapter for Gypsum Ceiling Thickness less than .875" (FMA3/087,FMA3SQ/087) 9/11/2018 View
    Installation Instructions P2908.pdf AX3 3" Round Ceiling Thickness Adapter .875" to 1.625" (CTA3/125,CTA3/163) 9/11/2018 View
    Installation Instructions P3647.pdf AX3 3" Round Flangeless Adapter for Wood, Stone & Tile Ceiling Thickness .875" to 1.625" (SFM3) 9/11/2018 View
    Installation Instructions P4482.pdf AX3 3" Round Flangeless Adapter for Gypsum Ceiling Thickness .875" to 1.625" (FMA3/125,FMA3/163) 9/11/2018 View
    Installation Instructions P4535.pdf AX3 and AX3SQ 3" New Construction Housing 2/9/2023 View
    Installation Instructions P4536.pdf AX3 3" Round Remodel Housing 8/24/2021 View
    Installation Instructions P6160.pdf AX3 and AX3SQ 3" DMX512/RDM Field Installation 6/5/2018 View

  • Utility Rebate Search

    To look-up a rebate for this product, please follow the steps below:

    Step 1: Enter the Zip Code or Select the State and Utility

    Step 2: Ensure that the correct Product Category is selected if there is more than one option


  • Replacement Parts

  • Confidential Documents

  • Marketing Material (e.g. Brochures, Sell Sheets, FAQs)

    Document Type Document Title Description Updated View
    Brochures Aculux 3-inch Precision Recessed LED Brochure_0318.pdf Aculux AX3 Brochure 10/4/2024 View
    Brochures ACX_5D Precision Spot Flyer.pdf Aculux 5 degree Precision Spot Flyer 7/12/2024 View
    Brochures ACX_AX3 & AX4 WD TW Brochure__WEB.pdf Aculux WarmDim® & Tunable White Brochure 10/4/2024 View
