Initia 3" Square Downlight

3" Value Precision Recessed New Construction & Remodel
    WarmDimEnergy Star®CA Title 24/JA8Buy America(n) Option AvailableBuy America(n) Option AvailableLow UGR
  • Overview
  • Specifications
Aculux® Initia 3-inch precision recessed downlight luminaire is quiet and elegant, delivering up to 1,500 lumens while providing:

Exceptional Performance for Budget-Sensitive projects:
  • Complete family of recessed downlight, adjustable, and wall wash luminaires
  • Coordinated apertures with the Aculux AX3 family
Quiet and Glare Free Apertures:
  • 45° visual cutoff to source and source image
Precision Optics:
  • Field interchangeable optics with distributions from 18° to 50°
Read More
Read Less
Aperture Size 3 IN
Shape Square
Light Source LED - Dynamic, LED - Static
Lumens 400 LM, 800 LM, 1000 LM, 1200 LM, 1500 LM
CCT / LED Color 2700 K, 3000 K, 3500 K, 4000 K, Variable
CRI 80, 90
Product Type Downlight
Compliance Listing BAA and BABA, CA Title 24, Chicago Plenum, ENERGY STAR®, JA8, Low UGR
Environmental Listing ASTM Airtight, Damp Location, IC, IP65, Non-IC, Wet Location
Regulatory Listing cUL, UL
Dimming Protocol 0-10V, Forward Phase, Reverse Phase
Fixture Wattage 12, 16, 5, 8
Voltage Rating 120, 120-277, 277
Trim Style Bevel, Lensed, Pinhole, Reflector
Color Black, Clear, Wheat, White
Mounting Type Recessed
Series INIT3SQ

Read More Read Less

  • Suggested Replacement Products

PRODUCT INFORMATION

  • Spec Sheets

    Document Type Document Title Description Updated View
    Spec Sheet INIT3SQ DL WW.pdf Initia Square Downlight/Wall Wash New Construction & Remodel 12/12/2024 View

    Design Select
    Take Me There
  • Photometry & Revit (BIM)

    Use %(percent) to separate search terms.

    1 - 1 of results

    Description Report Design Tools
    CLICK HERE to start your request for a BIM Model or IES file.
  • Technical Documents (e.g. Instruction Sheets, MSDS, CAD)

    Document Type Document Title Description Updated View
    Installation Instructions P4807.pdf INIT3 and INIT3SQ 3" New Construction Housing 5/4/2022 View
    Installation Instructions P4808.pdf INIT3 and INIT3SQ 3" Remodel Housing 5/4/2022 View
    Installation Instructions P4809.pdf INIT3 and INIT3SQ 3" Flangeless Adapter for Gypsum Ceiling Thickness .50" to 1.50" (NT3FMA) 3/11/2020 View
  • Utility Rebate Search

    To look-up a rebate for this product, please follow the steps below:

    Step 1Enter the Zip Code or Select the State and Utility

    Step 2Ensure that the correct Product Category is selected if there is more than one option


    Use the options below to ensure you get the results you're looking for

    Adjust your existing condition to make kWh calculations more accurate for custom rebates

    Filter the products shown so you only see the products that are relevant to you

    Wattage Range
    Lumen Range
    DLC/Energy Star
    Classification

    Choose which columns appear so you're comparing products using the right criteria

    LEGEND
    Product Page
    Spec Sheet Link
    Contractor Select
    DLC® Standard Screenshot
    DLC® Premium Screenshot
    DLC® Horticultural Screenshot
    ENERGY STAR® Screenshot
    PPEPhotosynthetic Photon Efficacy
    *Available through distributor only
    Utility
    undefined
    • Download current selection Download the products currently shown in the widget in the utility selected, with rebate estimates.
    • Download all products report Get emailed a report with all of this manufacturer's products with rebate estimates for a single utility.
  • Replacement Parts

  • Confidential Documents

  • Marketing Material (e.g. Brochures, Sell Sheets, FAQs)

    Document Type Document Title Description Updated View
    Brochures ACX_9976.02_Aculux Initia 3in Brochure_0120_web.pdf Aculux Initia Brochure 10/4/2024 View
  • Need Product Assistance? (e.g. How to Buy, Technical Support, Warranty)

    How to Buy

    Acuity Brands lighting and controls products are primarily sold through a network of agents and distributors across North America,
    as well as at more than 100 showroom or international locations and several online retailers.

    •  Find a Showroom or Agent


    Technical Support

    Acuity Brands is dedicated to providing outstanding technical support. Please click on the appropriate link below, or feel free to
    call us at 1.800.705.SERV (7378).

    •  FAQs

    •  Contact Us (Lighting Fixtures)

    •  Contact Us (Controls Services & Support)


    Warranty

    Please click on the appropriate link below to learn more about Acuity Brands terms & conditions and product warranty options.

    •  Review Terms & Conditions or Product Warranties

    •  Register a Recently Purchased Product

    •  File a Warranty Claim


Configurator

Build Cat. # / Submittal Spec Sheet

Design Select (15 days or less) Design Select Available

  • Start Configurating a Product

Product Family

Aculux

Initia™ Downlights | Aculux

Aculux initia™ downlights are our newest 3 inch architectural downlights with trim options, aiming control and adjustable beam a...

VIEW PRODUCT FAMILY
